CALIBRE 1300 https://www.fpjourne.com/en/collection/limited-series/octa-zodiaque FP Journe https://www.fpjourne.com/en FP Journe
Diameter: 40 mm
Overall height: 10.6 mm
Dial: slate grey Gold and whitened guilloché Silver
Hands: blued Steel
Technical Specifications
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Technical description
Technical description
Diameter: 40 mm
Overall height: 10.6 mm
Dial: slate grey Gold and whitened guilloché Silver
Hands: blued Steel
Diameter: 40 mm
Overall height: 10.6 mm
Dial: slate grey Gold and whitened guilloché Silver
Hands: blued Steel
Technical Specifications
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Technical description
Technical description
About
Limited Series numbered 1 to 150
Case 40mm in platinum with movement in brass
Through this creation, François-Paul Journe wished to make a graphic allusion to the stars, which have always served as points of reference for mankind in calculating time, and have also influenced human beliefs…
This watch is developed on the basis of the Octa mechanical self-winding calibre, providing an exceptional 120-hour power-reserve.
Like the sky chart zone - divided into twelve parts and marked out by two tiny circles parallel to the ecliptic and located at an angle of 8.5° and in which the apparent movement of the sun is depicted - the outer circle with the 12 hour graduations moves each day, driven by the large date system and thereby displaying the month and the sign of the zodiac at 12 o'clock.
The back of the 40 mm platinum case reveals the exclusive F.P. Journe mechanism, thus making it a limited edition within the collection. After the Octa Divine, this is the second model to feature central blued hour and minute hands. It also features a power-reserve indicator, large date display and sub-seconds at 5 o'clock.
Issued in a limited series of 150, the silver and slate grey 18-carat gold dial, confirms its resemblance to other models within the Octa collection.
Technical Specifications
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Technical description
Technical description
-
About
This model was produced between 2004 and 2006
Limited Series numbered 1 to 150
Case 40mm in platinum with movement in brass
Through this creation, François-Paul Journe wished to make a graphic allusion to the stars, which have always served as points of reference for mankind in calculating time, and have also influenced human beliefs…
This watch is developed on the basis of the Octa mechanical self-winding calibre, providing an exceptional 120-hour power-reserve.
Like the sky chart zone - divided into twelve parts and marked out by two tiny circles parallel to the ecliptic and located at an angle of 8.5° and in which the apparent movement of the sun is depicted - the outer circle with the 12 hour graduations moves each day, driven by the large date system and thereby displaying the month and the sign of the zodiac at 12 o'clock.
The back of the 40 mm platinum case reveals the exclusive F.P. Journe mechanism, thus making it a limited edition within the collection. After the Octa Divine, this is the second model to feature central blued hour and minute hands. It also features a power-reserve indicator, large date display and sub-seconds at 5 o'clock.
Issued in a limited series of 150, the silver and slate grey 18-carat gold dial, confirms its resemblance to other models within the Octa collection.
-
Technical description
Technical Specifications
Indications :Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.Dimensions :- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
Caracteristics :In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.Auto winding :274 anti clockwise revolution / 24 hours.
Main features :Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.Frequency :21'600 VPH, 3 Hz
Balance :- Inertia : 10.10 mgcm2
- Angle of lift : 52°
Amplitude :- 0h dial up : 280°
- 120h dial up : 220°
Power reserve :160 +/- 12 hours
Number of jewels :28
Finishing :High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.Number of components :- Movement : 235
- Cased on leather strap : 272
Indications :Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.Dimensions :- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
Caracteristics :In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.Auto winding :274 anti clockwise revolution / 24 hours.
Main features :Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.Frequency :21'600 VPH, 3 Hz
Balance :- Inertia : 10.10 mgcm2
- Angle of lift : 52°
Amplitude :- 0h dial up : 280°
- 120h dial up : 220°
Power reserve :160 +/- 12 hours
Number of jewels :28
Finishing :High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.Number of components :- Movement : 235
- Cased on leather strap : 272
At the heart of the movementAt the heart of the movementTechnical description
Technical description
Technical Specifications
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
Hours and minutes in the center.
Small seconds at 4:30.
Power reserve indicator at 7:30.
Month and zodiac signs at 12h00.
Large date at 11:30.
- Overall diameter of mvt : 30.80 mm
- Casing-up diameter of mvt : 30.40 mm
- Overall height of mvt : 5.70 mm
- Height of winding system : 3.00 mm
- Diameter of stem thread : S0.90 mm
In line lever escapement, 15 tooth wheel.
Balance with 4 inertia weights.
Free-sprung balance.
Flat Anachron microflamed spring.
Mobile stud holder.
Nivatronic laser-welded to the collet.
Pinned GE stud.
3 positions crown.
Slipping mainspring.
Off-centre winding rotor.
274 anti clockwise revolution / 24 hours.
Bi-directional automatic winding.
Date setting by turning crown in opposite ways (position 2).
Time setting with crown in position 3.
Instantaneous date change.
21'600 VPH, 3 Hz
- Inertia : 10.10 mgcm2
- Angle of lift : 52°
- 0h dial up : 280°
- 120h dial up : 220°
160 +/- 12 hours
28
High grade.
Circular stripes on bridges.
Baseplate circular-grained
Polished screws heads with
Chamfered slots.
Pegs with polished rounded ends.
Steelwork with polished chamfers.
- Movement : 235
- Cased on leather strap : 272
